LED surface-mounted luminaire with 3-phase track adapter
Direct only light distribution. Luminaire body with minimalistic overall height made of aluminium profile. Surface natural anodised or white, graphite, black or champagne coated. For further surface options see Lightnet-Surface-Collection or RAL of your choice. Microprismatic screen with optimized glare reduction for workplaces. Satin opal diffuser for general lighting with maximum transmittance and uniformity. Driver integrated into luminaire housing, optionally switchable or dimmable (DALI). Colour temperature 2200K, 2700K, 3000K, 3500K, 4000K or 6500K. Binning ≤ MacAdam 3. Colour rendering CRI>80, CRI>90 or Full Spectrum. Adapter for 3-phase adapter options, EUTRAC or GLOBAL. On request: Multi-sensor, integral emergency lighting module.
Product adjustments
Soft Edge: Multisensor
Sharp Edge: Multisensor
Snow White
Anodic Silver
Urban Graphite
Jet Black
Anodic Champagne
-
Snow White
-
Radiant Silver
-
Jet Black
-
Natural Anodised
-
Ivory White
-
Anodic Silver
-
Stone Grey
-
Urban Graphite
-
Anodic Bronze
-
Matte Terra
-
Medium Brass
-
Anodic Champagne
-
Satin Silver
-
Satin Taupe
-
Satin Cloud
-
Satin Gold
-
Satin Pale Gold
-
Satin Ivy Green
-
Satin Copper
-
Satin Cipria
-
Satin Bronze
-
Sustainability Plus Collection
In our Sustainability Plus Collection, we place a special focus on the sustainability of both the powder coatings and the production process. With the help of three fully automated production lines, we completely recover the powder coatings, use electric ovens powered by solar energy and minimise curing times.-
Snow White
-
Radiant Silver
-
Jet Black
-
Natural Anodised
-
-
Deep Matte Collection
For our Deep Matte Collection, we have carefully selected a range of surfaces with an outstanding deep matt and velvety elegance, ensuring a subtle and high-quality integration into the room architecture.-
Ivory White
-
Anodic Silver
-
Stone Grey
-
Urban Graphite
-
Anodic Bronze
-
Matte Terra
-
Medium Brass
-
Anodic Champagne
-
-
Satin Collection
Our Satin Collection impresses with its inimitable satin finish, excellent depth of colour and a subtle, fine sheen achieved through a special two-stage process. This collection offers top-class surfaces that bring the light to life.-
Satin Silver
-
Satin Taupe
-
Satin Cloud
-
Satin Gold
-
Satin Pale Gold
-
Satin Ivy Green
-
Satin Copper
-
Satin Cipria
-
Satin Bronze
-
Configuration and data download
| Downloads | Article code | Productname | Length L/Diameter D (mm) | Optical system | Surface finish | Colour temperature | Control | Adaptor | Frame Design | Luminous Flux | Power consumption |
|---|---|---|---|---|---|---|---|---|---|---|---|
| CC4OBE-830H-L1500-BC | Cubic-C4 | L=1500mm | Opal diffuser | Jet Black | 3000K | Switchable | Black adaptor (In-Track Electronic) | Sharp Edge | 4999lm | 41W | |
| CC4OWE-840H-L1500-WC | Cubic-C4 | L=1500mm | Opal diffuser | Snow White | 4000K | Switchable | White adaptor (In-Track Electronic) | Sharp Edge | 5180lm | 41W | |
| CC4OWL-840M-L1500-WC | Cubic-C4 | L=1500mm | Opal diffuser | Snow White | 4000K | Dimmable (DALI) | White adaptor (In-Track Electronic) | Sharp Edge | 3510lm | 28W | |
| CC4OWE-840M-L1500-WC | Cubic-C4 | L=1500mm | Opal diffuser | Snow White | 4000K | Switchable | White adaptor (In-Track Electronic) | Sharp Edge | 3510lm | 28W | |
| CC4OBE-830M-L1500-BC | Cubic-C4 | L=1500mm | Opal diffuser | Jet Black | 3000K | Switchable | Black adaptor (In-Track Electronic) | Sharp Edge | 3387lm | 28W | |
| CC4ABE-840H-L1200-BC | Cubic-C4 | L=1200mm | Microprismatic screen | Jet Black | 4000K | Switchable | Black adaptor (In-Track Electronic) | Sharp Edge | 4060lm | 33W | |
| CC4AWL-840H-L1500-WC | Cubic-C4 | L=1500mm | Microprismatic screen | Snow White | 4000K | Dimmable (DALI) | White adaptor (In-Track Electronic) | Sharp Edge | 5400lm | 41W | |
| CC4ABE-840H-L1500-BC | Cubic-C4 | L=1500mm | Microprismatic screen | Jet Black | 4000K | Switchable | Black adaptor (In-Track Electronic) | Sharp Edge | 5400lm | 41W | |
| CC4AWL-830H-L1500-WC | Cubic-C4 | L=1500mm | Microprismatic screen | Snow White | 3000K | Dimmable (DALI) | White adaptor (In-Track Electronic) | Sharp Edge | 5211lm | 41W | |
| CC4ABL-830H-L1500-BC | Cubic-C4 | L=1500mm | Microprismatic screen | Jet Black | 3000K | Dimmable (DALI) | Black adaptor (In-Track Electronic) | Sharp Edge | 5211lm | 41W |
