LED pendant luminaire
Completely configured light structure with all necessary light modules, connectors and cord-holders. Direct-indirect or direct-only light distribution. Luminaire body made of aluminium profile with 60mm profile width. Surface white, silver, graphite, black, champagne or copper coated. For further surface options see Lightnet-Surface-Collection or RAL of your choice. Optional integrated acoustic element for regulating reverberation time. Acoustic absorber for a wide frequency spectrum, made from sustainable wool or green moss. Satin opal diffuser for general lighting. Driver in each case integrated into luminaire housing, optionally switchable or dimmable (DALI, Touch-Dim, Casambi). Colour temperature 2200K, 2700K, 3000K, 3500K, 4000K or 6500K. Binning ≤ MacAdam 3. Colour rendering CRI>80, CRI>90 or Full Spectrum. Height-adjustable parallel cord suspension with transparent power supply cable. Ceiling rose to match luminaire body.
Product adjustments
Micro Perforated Snow White
Micro Perforated Luminaire Colour
Cloud Felt
Grey Felt
Black Felt
Green Moss
Beige Wool
Green Wool
-
Snow White
-
Radiant Silver
-
Jet Black
-
Natural Anodised
-
Ivory White
-
Anodic Silver
-
Stone Grey
-
Urban Graphite
-
Anodic Bronze
-
Matte Terra
-
Medium Brass
-
Anodic Champagne
-
Satin Silver
-
Satin Taupe
-
Satin Cloud
-
Satin Gold
-
Satin Pale Gold
-
Satin Ivy Green
-
Satin Copper
-
Satin Cipria
-
Satin Bronze
-
Beige Wool
-
Green Wool
-
Graphite Wool
-
Grey Felt
-
Black Felt
-
Green Fabric
-
Anthracite Fabric
-
Taupe Fabric
-
White Fabric
-
Micro Perforated
-
Moss
-
Sustainability Plus Collection
In our Sustainability Plus Collection, we place a special focus on the sustainability of both the powder coatings and the production process. With the help of three fully automated production lines, we completely recover the powder coatings, use electric ovens powered by solar energy and minimise curing times.-
Snow White
-
Radiant Silver
-
Jet Black
-
Natural Anodised
-
-
Deep Matte Collection
For our Deep Matte Collection, we have carefully selected a range of surfaces with an outstanding deep matt and velvety elegance, ensuring a subtle and high-quality integration into the room architecture.-
Ivory White
-
Anodic Silver
-
Stone Grey
-
Urban Graphite
-
Anodic Bronze
-
Matte Terra
-
Medium Brass
-
Anodic Champagne
-
-
Satin Collection
Our Satin Collection impresses with its inimitable satin finish, excellent depth of colour and a subtle, fine sheen achieved through a special two-stage process. This collection offers top-class surfaces that bring the light to life.-
Satin Silver
-
Satin Taupe
-
Satin Cloud
-
Satin Gold
-
Satin Pale Gold
-
Satin Ivy Green
-
Satin Copper
-
Satin Cipria
-
Satin Bronze
-
-
Acoustic Collection
Our carefully curated selection of ecological acoustic materials combines outstanding aesthetics with excellent acoustic performance.-
Beige Wool
-
Green Wool
-
Graphite Wool
-
Grey Felt
-
Black Felt
-
Green Fabric
-
Anthracite Fabric
-
Taupe Fabric
-
White Fabric
-
Micro Perforated
-
Moss
-
Configuration and data download
| Downloads | Article code | Productname | Length L/Diameter D (mm) | Optical system | Surface finish | Colour temperature | Control | Suspension | Luminous Flux | Power consumption |
|---|---|---|---|---|---|---|---|---|---|---|
| RG3ABE-830E-4R-K | Ringo Star Chain-G3 | L/D=3820/1000mm | Microprismatic screen | Jet Black | 3000K | Switchable | Parallel cord susp (Set) | 21037lm | 155W | |
| RG3ASE-840E-4R-K | Ringo Star Chain-G3 | L/D=3820/1000mm | Microprismatic screen | Radiant Silver | 4000K | Switchable | Parallel cord susp (Set) | 21800lm | 155W | |
| RG3AWE-827M-4R-K | Ringo Star Chain-G3 | L/D=3820/1000mm | Microprismatic screen | Snow White | 2700K | Switchable | Parallel cord susp (Set) | 32135lm | 225W | |
| RG3ABL-840E-4R-K | Ringo Star Chain-G3 | L/D=3820/1000mm | Microprismatic screen | Jet Black | 4000K | Dimmable (DALI) | Parallel cord susp (Set) | 21800lm | 155W | |
| RG3ASL-840E-4R-K | Ringo Star Chain-G3 | L/D=3820/1000mm | Microprismatic screen | Radiant Silver | 4000K | Dimmable (DALI) | Parallel cord susp (Set) | 21800lm | 155W | |
| RG3AWE-840E-4R-K | Ringo Star Chain-G3 | L/D=3820/1000mm | Microprismatic screen | Snow White | 4000K | Switchable | Parallel cord susp (Set) | 21800lm | 155W | |
| RG3ABE-827E-4R-K | Ringo Star Chain-G3 | L/D=3820/1000mm | Microprismatic screen | Jet Black | 2700K | Switchable | Parallel cord susp (Set) | 21037lm | 155W | |
| RG3ASE-830E-4R-K | Ringo Star Chain-G3 | L/D=3820/1000mm | Microprismatic screen | Radiant Silver | 3000K | Switchable | Parallel cord susp (Set) | 21037lm | 155W | |
| RG3AWE-830M-5R-K | Ringo Star Chain-G3 | L/D=4760/1000mm | Microprismatic screen | Snow White | 3000K | Switchable | Parallel cord susp (Set) | 40820lm | 286W | |
| RG3ABE-827M-5R-K | Ringo Star Chain-G3 | L/D=4760/1000mm | Microprismatic screen | Jet Black | 2700K | Switchable | Parallel cord susp (Set) | 40820lm | 286W |
