LED pendant luminaire
Direct-indirect or direct-only light distribution. Luminaire body made of aluminium profile with 60mm profile width. Surface white, silver, graphite, black, champagne or copper coated. For further surface options see Lightnet-Surface-Collection or RAL of your choice. Microprismatic screen with optimized glare reduction for workplaces. Satin opal diffuser for general lighting with maximum transmittance and uniformity. Driver integrated into luminaire housing, optionally switchable or dimmable (DALI, Touch-Dim, Casambi). Colour temperature 2200K, 2700K, 3000K, 3500K, 4000K, 6500K or Tunable White (2700-6500K). Binning ≤ MacAdam 3. Colour rendering CRI>80, CRI>90 or Full Spectrum. Height-adjustable central, parallel or disc cord suspension with transparent power supply cable. Ceiling rose to match luminaire body.
Product adjustments
Midpin Spotlight XP 770lm/10W/Ø40mm
Snow White
Radiant Silver
Urban Graphite
Jet Black
Anodic Champagne
Satin Copper
-
Snow White
-
Radiant Silver
-
Jet Black
-
Natural Anodised
-
Ivory White
-
Anodic Silver
-
Stone Grey
-
Urban Graphite
-
Anodic Bronze
-
Matte Terra
-
Medium Brass
-
Anodic Champagne
-
Satin Silver
-
Satin Taupe
-
Satin Cloud
-
Satin Gold
-
Satin Pale Gold
-
Satin Ivy Green
-
Satin Copper
-
Satin Cipria
-
Satin Bronze
-
Sustainability Plus Collection
In our Sustainability Plus Collection, we place a special focus on the sustainability of both the powder coatings and the production process. With the help of three fully automated production lines, we completely recover the powder coatings, use electric ovens powered by solar energy and minimise curing times.-
Snow White
-
Radiant Silver
-
Jet Black
-
Natural Anodised
-
-
Deep Matte Collection
For our Deep Matte Collection, we have carefully selected a range of surfaces with an outstanding deep matt and velvety elegance, ensuring a subtle and high-quality integration into the room architecture.-
Ivory White
-
Anodic Silver
-
Stone Grey
-
Urban Graphite
-
Anodic Bronze
-
Matte Terra
-
Medium Brass
-
Anodic Champagne
-
-
Satin Collection
Our Satin Collection impresses with its inimitable satin finish, excellent depth of colour and a subtle, fine sheen achieved through a special two-stage process. This collection offers top-class surfaces that bring the light to life.-
Satin Silver
-
Satin Taupe
-
Satin Cloud
-
Satin Gold
-
Satin Pale Gold
-
Satin Ivy Green
-
Satin Copper
-
Satin Cipria
-
Satin Bronze
-
Configuration and data download
| Downloads | Article code | Productname | Length L/Diameter D (mm) | Optical system | Surface finish | Colour temperature | Control | Suspension | Luminous Flux | Power consumption |
|---|---|---|---|---|---|---|---|---|---|---|
| RG4OSL-840H-D4000-K | Ringo Star-G4 | D=4000mm | Opal diffuser | Radiant Silver | 4000K | Dimmable (DALI) | Parallel cord susp (Set) | 25480lm | 209W | |
| RG4OBL-840H-D4000-K | Ringo Star-G4 | D=4000mm | Opal diffuser | Jet Black | 4000K | Dimmable (DALI) | Parallel cord susp (Set) | 25480lm | 209W | |
| RG4OSL-827H-D4000-K | Ringo Star-G4 | D=4000mm | Opal diffuser | Radiant Silver | 2700K | Dimmable (DALI) | Parallel cord susp (Set) | 24588lm | 209W | |
| RG4OWL-840M-D5000-K | Ringo Star-G4 | D=5000mm | Opal diffuser | Snow White | 4000K | Dimmable (DALI) | Parallel cord susp (Set) | 25480lm | 204W | |
| RG4ABE-840H-D4000-K | Ringo Star-G4 | D=4000mm | Microprismatic screen | Jet Black | 4000K | Switchable | Parallel cord susp (Set) | 27230lm | 209W | |
| RG4ABL-827H-D4000-K | Ringo Star-G4 | D=4000mm | Microprismatic screen | Jet Black | 2700K | Dimmable (DALI) | Parallel cord susp (Set) | 26277lm | 209W | |
| RG4AWL-830H-D4000-K | Ringo Star-G4 | D=4000mm | Microprismatic screen | Snow White | 3000K | Dimmable (DALI) | Parallel cord susp (Set) | 26277lm | 209W | |
| RG4ASL-827H-D4000-K | Ringo Star-G4 | D=4000mm | Microprismatic screen | Radiant Silver | 2700K | Dimmable (DALI) | Parallel cord susp (Set) | 26277lm | 209W | |
| RG4OSE-840H-D6000-K | Ringo Star-G4 | D=6000mm | Opal diffuser | Radiant Silver | 4000K | Switchable | Parallel cord susp (Set) | 39380lm | 319W | |
| RG4ASL-840H-D6000-K | Ringo Star-G4 | D=6000mm | Microprismatic screen | Radiant Silver | 4000K | Dimmable (DALI) | Parallel cord susp (Set) | 42090lm | 319W |
