LED recessed mounted light system
Housing:
Extruded Aluminum. LED recessed mounted light system. FX version with complete frame for ceilings. Version QX with frame on one side to allow mounting near walls. Direct only light distribution. Luminaire body with smooth bends made of profile with 1.625" optic width, crafted in one piece with no visible seams at the ends. Fully enclosed and damp rated.
Optical System:
Precision lenses with louver for wide uniform symmetrical light distribution with high glare limitation (UGR<19). Louver available in various color finishes. Satin opal diffuser for general lighting with maximum transmittance and homogeneous lighting.
Surface Finish:
Standard color finishes white, silver, graphite, black, champagne or copper coated. Further surface options see Lightnet-Surface-Collection. RAL or PANTONE of your choice.
Control:
Integral electronic driver dimmable 0-10V. Minimum dimming level 1%. Field replaceable. On request: DALI, DMX, Lutron, Casambi.
LED:
Available color temperatures: 2200K, 2700K, 3000K, 3500K, 4000K, 6500K. All color temperatures available in CRI>80 or CRI>90. Optionally FULL SPECTRUM-LEDS for highest Fidelity Levels (Tm30). Tolerance within a 3 -step MacAdam ellipse. Up to 110lm/W efficacy. Choice of different lumen output levels: Low, Medium, or High Power. Custom lumen output upon request. Lifetime L85/50000h.
Certification & Warranty:
cETLus.
5 Years Warranty.
Product adjustments
Linear Modules
Bend Modules
Curve Modules
Wave Modules
Y-Modules
X-Modules
-
Snow White
-
Radiant Silver
-
Jet Black
-
Natural Anodised
-
Ivory White
-
Anodic Silver
-
Stone Grey
-
Urban Graphite
-
Anodic Bronze
-
Matte Terra
-
Medium Brass
-
Anodic Champagne
-
Satin Silver
-
Satin Taupe
-
Satin Cloud
-
Satin Gold
-
Satin Pale Gold
-
Satin Ivy Green
-
Satin Copper
-
Satin Cipria
-
Satin Bronze
-
Sustainability Plus Collection
In our Sustainability Plus Collection, we place a special focus on the sustainability of both the powder coatings and the production process. With the help of three fully automated production lines, we completely recover the powder coatings, use electric ovens powered by solar energy and minimise curing times.-
Snow White
-
Radiant Silver
-
Jet Black
-
Natural Anodised
-
-
Deep Matte Collection
For our Deep Matte Collection, we have carefully selected a range of surfaces with an outstanding deep matt and velvety elegance, ensuring a subtle and high-quality integration into the room architecture.-
Ivory White
-
Anodic Silver
-
Stone Grey
-
Urban Graphite
-
Anodic Bronze
-
Matte Terra
-
Medium Brass
-
Anodic Champagne
-
-
Satin Collection
Our Satin Collection impresses with its inimitable satin finish, excellent depth of colour and a subtle, fine sheen achieved through a special two-stage process. This collection offers top-class surfaces that bring the light to life.-
Satin Silver
-
Satin Taupe
-
Satin Cloud
-
Satin Gold
-
Satin Pale Gold
-
Satin Ivy Green
-
Satin Copper
-
Satin Cipria
-
Satin Bronze
-
Configuration and data download
| Downloads | Article code | Productname | Optical system | Surface finish | Color temperature | Control | Reflector Color Inside | Luminous Flux | Power consumption |
|---|---|---|---|---|---|---|---|---|---|
| 1QFXLWE-840E-STRUCTURE_Lxxxx-W | Liquid Line-FX | Lens Louver | Snow White | 4000K | Switchable | Reflector: Snow White | 520lm/feet | 4W/feet | |
| 1QFXLWE-830E-STRUCTURE_Lxxxx-W | Liquid Line-FX | Lens Louver | Snow White | 3000K | Switchable | Reflector: Snow White | 486lm/feet | 4W/feet | |
| 1QFXLWE-840H-STRUCTURE_Lxxxx-W | Liquid Line-FX | Lens Louver | Snow White | 4000K | Switchable | Reflector: Snow White | 960lm/feet | 7W/feet | |
| 1QFXLWE-830H-STRUCTURE_Lxxxx-W | Liquid Line-FX | Lens Louver | Snow White | 3000K | Switchable | Reflector: Snow White | 898lm/feet | 7W/feet | |
| 1QFXLWD-840E-STRUCTURE_Lxxxx-W | Liquid Line-FX | Lens Louver | Snow White | 4000K | Dimmable (0-10V) | Reflector: Snow White | 520lm/feet | 4W/feet | |
| 1QFXLWD-830E-STRUCTURE_Lxxxx-W | Liquid Line-FX | Lens Louver | Snow White | 3000K | Dimmable (0-10V) | Reflector: Snow White | 486lm/feet | 4W/feet | |
| 1QFXLWD-840H-STRUCTURE_Lxxxx-W | Liquid Line-FX | Lens Louver | Snow White | 4000K | Dimmable (0-10V) | Reflector: Snow White | 960lm/feet | 7W/feet | |
| 1QFXLWD-830H-STRUCTURE_Lxxxx-W | Liquid Line-FX | Lens Louver | Snow White | 3000K | Dimmable (0-10V) | Reflector: Snow White | 898lm/feet | 7W/feet | |
| 1QFXLWE-840E-STRUCTURE_Lxxxx-B | Liquid Line-FX | Lens Louver | Snow White | 4000K | Switchable | Reflector: Jet Black | 520lm/feet | 4W/feet | |
| 1QFXLWE-830E-STRUCTURE_Lxxxx-B | Liquid Line-FX | Lens Louver | Snow White | 3000K | Switchable | Reflector: Jet Black | 486lm/feet | 4W/feet |
