LED surface-mounted luminaire
Housing:
Extruded Aluminum. LED surface-mounted luminaire made of 3.25" wide profile. Direct only light distribution. Bespoke lengths possible. Fully enclosed and damp rated.
Optical System:
Microprismatic screen made of special acrylic glass and satin louver made of aluminum with optimized glare reduction especially for workplaces. Satin opal diffuser for general lighting with maximum transmittance and homogeneous lighting. Wallwasher for homogeneous illumination of vertical surfaces.
Surface Finish:
Surface natural anodized or white, graphite, black or champagne coated. Further surface options see Lightnet-Surface-Collection. RAL or PANTONE of your choice.
Control:
Integral electronic driver dimmable 0-10V. Minimum dimming level 1%. Field replaceable. On request: DALI, DMX, Lutron, Casambi.
LED:
Available color temperatures: 2200K, 2700K, 3000K, 3500K, 4000K, 6500K, or Tunable White. All color temperatures available in CRI>80 or CRI>90. Optionally FULL SPECTRUM-LEDS for highest Fidelity Levels (Tm30). Tolerance within a 3-step MacAdam ellipse. Up to 110lm/W efficacy. Choice of different lumen output levels: Low, Medium, or High Power. Custom lumen output upon request. Lifetime L85/50000h.
Certification & Warranty:
cETLus. 5 Years Warranty.
Product adjustments
90° Corner Opal/Microprismatic
On request: Soft Edge Endcap
Multisensor
Snow White
Natural Anodised
Urban Graphite
Jet Black
Anodic Champagne
Satin Copper
-
Snow White
-
Radiant Silver
-
Jet Black
-
Natural Anodised
-
Ivory White
-
Anodic Silver
-
Stone Grey
-
Urban Graphite
-
Anodic Bronze
-
Matte Terra
-
Medium Brass
-
Anodic Champagne
-
Satin Silver
-
Satin Taupe
-
Satin Cloud
-
Satin Gold
-
Satin Pale Gold
-
Satin Ivy Green
-
Satin Copper
-
Satin Cipria
-
Satin Bronze
-
Pale Oak
-
Amber Oak
-
Midnight Ebony
-
Real Wood dark
-
Real Wood light
-
Sustainability Plus Collection
In our Sustainability Plus Collection, we place a special focus on the sustainability of both the powder coatings and the production process. With the help of three fully automated production lines, we completely recover the powder coatings, use electric ovens powered by solar energy and minimise curing times.-
Snow White
-
Radiant Silver
-
Jet Black
-
Natural Anodised
-
-
Deep Matte Collection
For our Deep Matte Collection, we have carefully selected a range of surfaces with an outstanding deep matt and velvety elegance, ensuring a subtle and high-quality integration into the room architecture.-
Ivory White
-
Anodic Silver
-
Stone Grey
-
Urban Graphite
-
Anodic Bronze
-
Matte Terra
-
Medium Brass
-
Anodic Champagne
-
-
Satin Collection
Our Satin Collection impresses with its inimitable satin finish, excellent depth of colour and a subtle, fine sheen achieved through a special two-stage process. This collection offers top-class surfaces that bring the light to life.-
Satin Silver
-
Satin Taupe
-
Satin Cloud
-
Satin Gold
-
Satin Pale Gold
-
Satin Ivy Green
-
Satin Copper
-
Satin Cipria
-
Satin Bronze
-
-
Wood Collection
The new wood surfaces combine technical precision with natural aesthetics and open up a wide range of possibilities for harmonious integration into architectural interior designs. Available as high-quality real wood veneer or decorative foil with a tactile texture, they offer authentic materiality – from Scandinavian lightness to deep elegance. The wood surfaces are available for the Matric, Liquid Line, Basic and Cubic luminaire families.-
Pale Oak
-
Amber Oak
-
Midnight Ebony
-
Real Wood dark
-
Real Wood light
-
Configuration and data download
| Downloads | Article code | Productname | Length L/Diameter D (in) | Optical system | Surface finish | Color temperature | Control | Reflector Color Inside | Luminous Flux | Power consumption |
|---|---|---|---|---|---|---|---|---|---|---|
| 1LA5LWE-835H-Lxxxx-W | Matric-A5 | L=xxxx'' | Lens Louver | Snow White | 3500K | Switchable | Reflector: Snow White | 1830lm/ft | 13W/ft | |
| 1LA5LWE-840H-Lxxxx-W | Matric-A5 | L=xxxx'' | Lens Louver | Snow White | 4000K | Switchable | Reflector: Snow White | 1830lm/ft | 13W/ft | |
| 1LA5LWD-830E-Lxxxx-W | Matric-A5 | L=xxxx'' | Lens Louver | Snow White | 3000K | Dimmable (0-10V) | Reflector: Snow White | 617lm/ft | 5W/ft | |
| 1LA5LWD-835E-Lxxxx-W | Matric-A5 | L=xxxx'' | Lens Louver | Snow White | 3500K | Dimmable (0-10V) | Reflector: Snow White | 660lm/ft | 5W/ft | |
| 1LA5LWD-840E-Lxxxx-W | Matric-A5 | L=xxxx'' | Lens Louver | Snow White | 4000K | Dimmable (0-10V) | Reflector: Snow White | 660lm/ft | 5W/ft | |
| 1LA5LEE-840M-L1506-A | Matric-A5 | L=59,3'' | Lens Louver | Silver Anodised | 4000K | Switchable | Reflector: Satin Silver | 6500lm | 46W | |
| 1LA5LBE-835H-L754-B | Matric-A5 | L=29,7'' | Lens Louver | Jet Black | 3500K | Switchable | Reflector: Jet Black | 4510lm | 32W | |
| 1LA5LBE-840H-L754-B | Matric-A5 | L=29,7'' | Lens Louver | Jet Black | 4000K | Switchable | Reflector: Jet Black | 4510lm | 32W | |
| 1LA5LEE-830H-L1506-A | Matric-A5 | L=59,3'' | Lens Louver | Silver Anodised | 3000K | Switchable | Reflector: Satin Silver | 8462lm | 64W | |
| 1LA5LEE-835H-L1506-A | Matric-A5 | L=59,3'' | Lens Louver | Silver Anodised | 3500K | Switchable | Reflector: Satin Silver | 9050lm | 64W |
