LED pendant luminaire
Housing:
Extruded Aluminum. LED pendant luminaire made of 3.25"
wide profile. Direct/Indirect or Direct Only light distribution.
Bespoke lengths are possible. Fully enclosed and damp rated.
Optical System:
Microprismatic screen made of special acrylic glass and satin
louver made of aluminum with optimized glare reduction especially
for workplaces. Satin opal diffuser for general lighting with
maximum transmittance and homogeneous lighting. Wallwasher
for homogeneous illumination of vertical surfaces.
Finish:
Surface natural anodized or white, graphite, black, champagne
or copper coated. Further surface options see Lightnet-Surface-
-Collection. RAL or PANTONE of your choice.
Control:
Integral electronic driver dimmable 0–10V. Minimum dimming level 1%.
Field replaceable. On request: DALI, DMX, Lutron, Casambi.
LED:
Available color temperatures: 2200K, 2700K, 3000K, 3500K, 4000K,
6500K, or Tunable White. All color temperatures available in CRI>80
or CRI>90. Optionally Full spectrum LEDs for highest Fidelity
Levels (Tm30). Tolerance within a 3 -step MacAdam ellipse.
From 120lm/W efficacy. Choice of different lumen output levels:
Low, Medium, or High Power. Custom lumen output upon request.
Lifetime minimum 50,000 hours with 85% of lumen maintenance.
Installation:
Height-adjustable Y-cord suspension with transparent power
supply cable. Canopy finish matches luminaire housing to luminaire
body.
Certification:
cETLus.
5-year limited warranty.
Product adjustments
On request: Soft Edge Endcap
90° Corner Opal/Microprismatic
Midpin XD Downlight
Midpin XP Spotlight
Midpin XM Downlight
-
Snow White
-
Radiant Silver
-
Jet Black
-
Natural Anodised
-
Ivory White
-
Anodic Silver
-
Stone Grey
-
Urban Graphite
-
Anodic Bronze
-
Matte Terra
-
Medium Brass
-
Anodic Champagne
-
Satin Silver
-
Satin Taupe
-
Satin Cloud
-
Satin Gold
-
Satin Pale Gold
-
Satin Ivy Green
-
Satin Copper
-
Satin Cipria
-
Satin Bronze
-
Sustainability Plus Collection
In our Sustainability Plus Collection, we place a special focus on the sustainability of both the powder coatings and the production process. With the help of three fully automated production lines, we completely recover the powder coatings, use electric ovens powered by solar energy and minimise curing times.-
Snow White
-
Radiant Silver
-
Jet Black
-
Natural Anodised
-
-
Deep Matte Collection
For our Deep Matte Collection, we have carefully selected a range of surfaces with an outstanding deep matt and velvety elegance, ensuring a subtle and high-quality integration into the room architecture.-
Ivory White
-
Anodic Silver
-
Stone Grey
-
Urban Graphite
-
Anodic Bronze
-
Matte Terra
-
Medium Brass
-
Anodic Champagne
-
-
Satin Collection
Our Satin Collection impresses with its inimitable satin finish, excellent depth of colour and a subtle, fine sheen achieved through a special two-stage process. This collection offers top-class surfaces that bring the light to life.-
Satin Silver
-
Satin Taupe
-
Satin Cloud
-
Satin Gold
-
Satin Pale Gold
-
Satin Ivy Green
-
Satin Copper
-
Satin Cipria
-
Satin Bronze
-
Configuration and data download
| Downloads | Article code | Productname | Optical system | Surface finish | Color temperature | Control | Suspension | Reflector Color Inside | Luminous Flux | Power consumption |
|---|---|---|---|---|---|---|---|---|---|---|
| 1LR6LWE-835H-L1256-YG | Matric-R6 | Lens Louver | Snow White | 3500K | Switchable | Y-susp. (Set) | Reflector: Satin Gold | 9534lm | 64W | |
| 1LR6LED-835M-L1256-YA | Matric-R6 | Lens Louver | Natural Anodised | 3500K | Dimmable (0-10V) | Y-susp. (Set) | Reflector: Satin Silver | 7160lm | 47W | |
| 1LR6LWD-835E-L2009-YG | Matric-R6 | Lens Louver | Snow White | 3500K | Dimmable (0-10V) | Y-susp. (Set) | Reflector: Satin Gold | 7913lm | 54W | |
| 1LR6LWD-840H-L2009-YD | Matric-R6 | Lens Louver | Snow White | 4000K | Dimmable (0-10V) | Y-susp. (Set) | Reflector: Anodic Black | 16370lm | 105W | |
| 1LR6LWE-840E-L1507-YD | Matric-R6 | Lens Louver | Snow White | 4000K | Switchable | Y-susp. (Set) | Reflector: Anodic Black | 6030lm | 39W | |
| 1LR6LWE-835M-L1005-YD | Matric-R6 | Lens Louver | Snow White | 3500K | Switchable | Y-susp. (Set) | Reflector: Anodic Black | 5587lm | 38W | |
| 1LR6LBD-835M-L2009-YG | Matric-R6 | Lens Louver | Jet Black | 3500K | Dimmable (0-10V) | Y-susp. (Set) | Reflector: Satin Gold | 11860lm | 78W | |
| 1LR6GBE-830E-L2055-Y | Matric-R6 | Wall-Washer | Jet Black | 3000K | Switchable | Y-susp. (Set) | 6909lm | 47W | ||
| 1LR6LWE-830M-L755-YD | Matric-R6 | Lens Louver | Snow White | 3000K | Switchable | Y-susp. (Set) | Reflector: Anodic Black | 4063lm | 30W | |
| 1LR6LWE-835E-L1507-YD | Matric-R6 | Lens Louver | Snow White | 3500K | Switchable | Y-susp. (Set) | Reflector: Anodic Black | 5819lm | 39W |
