LED pendant luminaire with a rebated lens optic in a decorative ring
Housing:
High-quality processed FRP (Fiberglass Reinforced Plastic). Direct/Indirect or Direct Only light distribution. Fully enclosed.
Optical System:
Microprismatic screen with optimized glare reduction especially for workplaces. Satin opal diffuser for general lighting with maximum transmittance and homogeneous lighting.
Finish:
Outer housing and Decorative reflector ring available in various finishes and combinations, e.g. white, silver, graphite, black, gold or copper coated. For further surface options see Lightnet-Surface-Collection. RAL or PANTONE of your choice.
Control:
Integral electronic driver dimmable 0–10V. Minimum dimming level 1%. Field replaceable. On request: DALI, DMX, Lutron, Casambi.
LED:
Available color temperatures: 2200K, 2700K, 3000K, 3500K, 4000K, 6500K, or Tunable White. All color temperatures available in CRI>80 or CRI>90. Tolerance within a 3-step MacAdam ellipse. From 120lm/W efficacy. Choice of different lumen output levels: Medium or High Power. Custom lumen output upon request. Lifetime minimum 50,000 hours with 85% of lumen maintenance.
Installation:
Height-adjustable central cord suspension, parallel cord suspension with transparent power supply cable, or rod suspension. Colors ceiling rose and rod suspension match to luminaire body.
Certification:
cETLus.
5-year limited warranty.
Product adjustments
Anodic Champagne | Satin Silver
Jet Black | Anodic Black
Anodic Champagne | Anodic Black
Jet Black | Satin Gold
Jet Black | Snow White
-
Snow White
-
Radiant Silver
-
Jet Black
-
Natural Anodised
-
Ivory White
-
Anodic Silver
-
Stone Grey
-
Urban Graphite
-
Anodic Bronze
-
Matte Terra
-
Medium Brass
-
Anodic Champagne
-
Satin Silver
-
Satin Taupe
-
Satin Cloud
-
Satin Gold
-
Satin Pale Gold
-
Satin Ivy Green
-
Satin Copper
-
Satin Cipria
-
Satin Bronze
-
Sustainability Plus Collection
In our Sustainability Plus Collection, we place a special focus on the sustainability of both the powder coatings and the production process. With the help of three fully automated production lines, we completely recover the powder coatings, use electric ovens powered by solar energy and minimise curing times.-
Snow White
-
Radiant Silver
-
Jet Black
-
Natural Anodised
-
-
Deep Matte Collection
For our Deep Matte Collection, we have carefully selected a range of surfaces with an outstanding deep matt and velvety elegance, ensuring a subtle and high-quality integration into the room architecture.-
Ivory White
-
Anodic Silver
-
Stone Grey
-
Urban Graphite
-
Anodic Bronze
-
Matte Terra
-
Medium Brass
-
Anodic Champagne
-
-
Satin Collection
Our Satin Collection impresses with its inimitable satin finish, excellent depth of colour and a subtle, fine sheen achieved through a special two-stage process. This collection offers top-class surfaces that bring the light to life.-
Satin Silver
-
Satin Taupe
-
Satin Cloud
-
Satin Gold
-
Satin Pale Gold
-
Satin Ivy Green
-
Satin Copper
-
Satin Cipria
-
Satin Bronze
-
Configuration and data download
| Downloads | Article code | Productname | Length L/Diameter D (in) | Optical system | Surface finish | Color temperature | Control | Suspension | Reflector Color Inside | Luminous Flux | Power consumption |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 1MP3OFD-840H-D650-KA | Beam Me Up-P3 | D=25,6'' | Opal diffuser | Anodic Silver | 4000K | Dimmable (0-10V) | Parallel cord susp (Set) | Reflector: Satin Silver | 8880lm | 59W | |
| 1MP3ODD-840H-D650-KG | Beam Me Up-P3 | D=25,6'' | Opal diffuser | Anodic Black | 4000K | Dimmable (0-10V) | Parallel cord susp (Set) | Reflector: Satin Gold | 8880lm | 59W | |
| 1MP3OFE-840M-D450-KA | Beam Me Up-P3 | D=17,7'' | Opal diffuser | Anodic Silver | 4000K | Switchable | Parallel cord susp (Set) | Reflector: Satin Silver | 2970lm | 20W | |
| 1MP3ODE-840M-D450-KG | Beam Me Up-P3 | D=17,7'' | Opal diffuser | Anodic Black | 4000K | Switchable | Parallel cord susp (Set) | Reflector: Satin Gold | 2970lm | 20W | |
| 1MP3OFD-827M-D450-KA | Beam Me Up-P3 | D=17,7'' | Opal diffuser | Anodic Silver | 2700K | Dimmable (0-10V) | Parallel cord susp (Set) | Reflector: Satin Silver | 2866lm | 20W | |
| 1MP3ADE-827M-D650-KG | Beam Me Up-P3 | D=25,6'' | Microprismatic screen | Anodic Black | 2700K | Switchable | Parallel cord susp (Set) | Reflector: Satin Gold | 5935lm | 40W | |
| 1MP3OFD-840M-D450-KA | Beam Me Up-P3 | D=17,7'' | Opal diffuser | Anodic Silver | 4000K | Dimmable (0-10V) | Parallel cord susp (Set) | Reflector: Satin Silver | 2970lm | 20W | |
| 1MP3AFD-840M-D850-KA | Beam Me Up-P3 | D=33,5'' | Microprismatic screen | Anodic Silver | 4000K | Dimmable (0-10V) | Parallel cord susp (Set) | Reflector: Satin Silver | 10740lm | 70W | |
| 1MP3ADD-840M-D850-KG | Beam Me Up-P3 | D=33,5'' | Microprismatic screen | Anodic Black | 4000K | Dimmable (0-10V) | Parallel cord susp (Set) | Reflector: Satin Gold | 10740lm | 70W | |
| 1MP3ADD-840H-D850-UG | Beam Me Up-P3 | D=33,5'' | Microprismatic screen | Anodic Black | 4000K | Dimmable (0-10V) | Central cord susp. (Set) | Reflector: Satin Gold | 13650lm | 90W |
